Model:M8400
● 84" TFT LCD monitor,
● 3840x2160,1920x1080 resolution (16:9),
● 1400:1 contrast ratio,
● 350 cd/㎡ brightness ,
● 8 ms quick response ,
● Over MTBF 60,000 hours above lifespan, 7x24 hours working,
● PIP &POP
● Metallic housing
Features
● 84" TFT LCD monitor,
● 3840x2160,1920x1080 resolution (16:9),
● 1400:1 contrast ratio,
● 350 cd/㎡ brightness ,
● 8 ms quick response ,
● Over MTBF 60,000 hours above lifespan, 7x24 hours working,
● PIP &POP
● Metallic housing
Specifications
| Technical Parameters: | |
| Model | M8400 |
| Panel size | 84" TFT-LCD |
| Active area | 1904.0×1096.0 |
| Colors | 16.7M |
| Resolution | Ultra FHD 3840x2160 ;1920x1080 (16:9) |
| Pixel Pitch | 0.4845×0.4845 |
| Brightness | 350cd/㎡ |
| Contrast Ratio | 1400:1 |
| View angle | 178°/178° |
| Response time | 8ms |
| Portrait/Landscape | Portrait mode |
| Material of housing | Aluminum front bezel, Metallic back cover |
| Color of housing | Black |
| Systems | PAL/NTSC |
| Android O/S version | V 4.0 |
| Operation method | Button & Remote controller |
| OSD languages | Chinese, English, multi-languages optional |
| HDMI input | 1x HDMI |
| DVI input | N/A |
| VGA input | 1x VGA (D-SUB) |
| Component video input (YPbPr) | 3x BNC(CVBS) |
| Audio In | 2 x Stereo Audio (*3.5mm mini jack) |
| Audio Out(Speakers) | 8 ohm, 10 W*2, |
| USB port | 3x USB 2.0, 1x USB 3.0, |
| RJ45 | 1XRJ45 |
| Earphone | 1xEarphone |
| Frequency | 50Hz, 60Hz, 70Hz,75Hz |
| Power supply | AC100~240V,50/60Hz |
| Power consumption | ≤500W |
| Standby power consumption | 3W |
| Operation temperature | 0℃~50℃ |
| Storage temperature | Minus 20℃~+60℃ |
| Operation & Storage humidity | 20%~80% |
| Installation methods | wall-mount,floor standing mount |
| Accessory | 1x User Manual |
| 1 x wall mount bracket | |
| 1x Remote control | |
| 1x VGA Cable/DVI Cable/HDMI Cable(one of 3) | |
| Audio Cable(optional) | |
| 1xDVI to HDMI converter with cable | |
| 1x Power Cord | |
| Dimension of monitor | monitor size: 1963.50*1149.40*107.20mm ;1963.50*1149.40*152.70mm(including wall mounting) ; |
| Net Weight | 160.0KG |
| Gross Weight | 170.5KG |
